Today we’re gonna build something. We’re gonna make a sawtooth wave. It’s called a sawtooth wave Well because it looks like this and it sounds like this But sawtooth wave forms are kind of like the party wave form I say that because these wave forms have lots of high frequency content Watch the sawtooth wave take shape as I load multiples of this 200 cycle per second sine wave 200 400 800 10000 A square wave only has the odd numbered harmonics And triangle waves are just going to taper off a little more quickly But because the sawtooth wave contains both odd and even harmonics you can think of it as one half of a triangle wave and the other half a Square wave it’s like a mullet business in the front party in the back at the back.
